Drivetrain
Chain Case Chain
520 X-Ring 52 Link (continuous)
Disc Brake Type
Wilwood Hydraulic Dual Piston
Drive Chain
520 X-Ring 70 link (master link)
Jack Shaft Sprocket
17 tooth - 15t spline
Lower Chain Case Sprocket
17 tooth - 15t spline
Upper Chain Case Sprocket
18 tooth - 15t spline
Front Suspension
Front Track Shock
Walker Evans Racing® Velocity Needle
Rear Suspension
Timbersled ARO™ Long Travel
Rear Track Shock
WER® Velocity Needle
Rear Travel - Fixed Install Kit (in/cm)
12 / 30.5
Rear Travel - TSS Install Kit (in/cm)
20 / 50.8
Skag Type
Timbersled Traverse™ Hardened
Ski Type
Timbersled Traverse Ski™
Track Width / Length / Height (in)
11.5 x 129 x 2.5 Traverse Track™
